Electric Cable NYA 50 mm² Kabelmetal Indonesia Copper PVC 450/750 V
General Description
NYA 50 mm² is a single-core copper cable with high-quality PVC insulation, designed for large-scale power distribution in commercial and industrial systems. Fully compliant with SNI 04-6629.3:2006 and IEC 60227-3.
Technical Specifications
Construction Data
| Nominal Cross Section Area | 50 mm² |
| Overall Diameter | 12.1 mm |
| Cable Weight | 513 kg/km |
| Conductor | Copper |
| Insulation | PVC |
| Rated Voltage | 450/750 V |
| Certification | SNI & IEC |
Electrical Data
| DC Resistance (20°C) | 0.387 Ω/km |
| AC Resistance (70°C) | 0.464 Ω/km |
| Insulation Resistance (70°C) | 45 MΩ·km |
| Inductance | 0.248 mH/km |
| Current Capacity in Conduit | 132 A |
| Current Capacity in Air | 197 A |
| Short-Circuit Current (1 sec) | 5.75 kA |
Applications
- Main power distribution for buildings and industrial zones
- Feeder cable between main panels
- Installed in trays, ducts, or conduit systems
Product Advantages
- High-grade copper conductor for optimal efficiency
- PVC insulation with heat and abrasion resistance
- High current capacity up to 197 A in air
- SNI & IEC certification ensures performance and safety
- Tin-coated copper option available
Special Features (on Request)
- Tin-coated copper conductor
- Fire and oil resistant
- Flame Retardant Cat. A, B, C
- Nylon coating for added durability
Note
- Conductor Shape: stranded (rm)
Standard Packing
- ≥25 mm²: wooden drum @1000 m
- Length tolerance: ±2%
